Object Detection as Probabilistic Set Prediction [ECCV2022]

This is the official implementation of the ECCV 2022 paper Object Detection as Probabilistic Set Prediction.

Project page

The code builds upon the probabilisitc detectron2 repository.

Disclaimer

This research code was produced by one person with a single set of eyes, it may contain bugs and errors that I did not notice by the time of release.

Todo's

• Release code
• Create nice API for evaluating arbitrary model with PMB-NLL
• Create nice API for use MB-NLL as loss function with any object detector

Requirements

Software Support:

Name	Supported Versions
Ubuntu	20.04
Python	3.8
CUDA	11.0+
Cudnn	8.0.1+
PyTorch	1.8+

To install requirements we provide a docker image using the provided Dockerfile.

Docker Image

cd Docker

# Build docker image
sh build.sh

You also need to build the fastmurty package used for solving optimal assignment problem.

cd src/core/fastmurty
make

Datasets

COCO Dataset

Download the COCO Object Detection Dataset here. The COCO dataset folder should have the following structure:

 └── COCO_DATASET_ROOT
     |
     ├── annotations
     ├── train2017
     └── val2017

Training

To train the models in the paper, use this command:

python src/train_net.py
--num-gpus xx
--dataset-dir COCO_DATASET_ROOT
--config-file COCO-Detection/architecture_name/config_name.yaml
--resume

For an explanation of all command line arguments, use python src/train_net.py -h

Evaluation

To run model inference after training, use this command:

python src/apply_net.py
--dataset-dir TEST_DATASET_ROOT
--test-dataset test_dataset_name
--config-file path/to/config.yaml
--inference-config /path/to/inference/config.yaml

For an explanation of all command line arguments, use python src/apply_net.py -h

--test-dataset should be coco_2017_custom_val, --dataset-dir corresponds to the root directory of the dataset used. Evaluation code will run inference on the test dataset and then will generate mAP and PMB-NLL. Also, the Negative Log Likelihood, Brier Score, Energy Score, and Calibration Error results following Estimating and Evaluating Regression Predictive Uncertainty in Deep Object Detectors are reported. If only evaluation of metrics is required, add --eval-only to the above code snippet.

Inference on new images

We provide a script to perform inference on new images without passing through dataset handlers.

python single_image_inference.py
--image-dir /path/to/image/dir
--output-dir /path/to/output/dir
--config-file /path/to/config/file
--inference-config /path/to/inference/config
--model-ckpt /path/to/model.pth

image-dir is a folder containing all images to be used for inference. output-dir is a folder to write the output json file containing probabilistic detections. model-ckpt is the path to the model checkpoint to be used for inference. Look below to download model checkpoints.

Configurations in the paper

We provide a list of config combinations that generate the architectures used in our paper, and for pretrained models we provide links to where they can be downloaded.

Method Name	Config File	Inference Config File	Model
RetinaNet NLL	retinanet_R_50_FPN_3x_reg_var_nll.yaml	standard_nms.yaml	retinanet_R_50_FPN_3x_reg_var_nll.pth
RetinaNet ES	retinanet_R_50_FPN_3x_reg_var_es.yaml	standard_nms.yaml	retinanet_R_50_FPN_3x_reg_var_es.pth
RetinaNet MB-NLL	retinanet_R_50_FPN_3x_reg_var_pmbnll_esbase.yaml	standard_nms.yaml	No pretained weights for blind review
---	---	---	---
FasterRCNN NLL	faster_rcnn_R_50_FPN_3x_reg_covar_nll.yaml	standard_nms.yaml	faster_rcnn_R_50_FPN_3x_reg_covar_nll.pth
FasterRCNN ES	faster_rcnn_R_50_FPN_3x_reg_var_es.yaml	standard_nms.yaml	faster_rcnn_R_50_FPN_3x_reg_var_es.pth
FasterRCNN MB-NLL	faster_rcnn_R_50_FPN_3x_reg_var_pmbnll_esbase.yaml	standard_nms.yaml	No pretained weights for blind review
---	---	---	---
DETR NLL	detr_R_50_reg_var_nll.yaml	topk_detections.yaml	detr_R_50_reg_var_nll.pth
DETR ES	detr_R_50_reg_var_es.yaml	topk_detections.yaml	detr_R_50_reg_var_es.pth
DETR MB-NLL	detr_R_50_reg_var_pmbnll_esbase.yaml	topk_detections.yaml	No pretained weights for blind review

Citation

If you find this work useful, please consider citing

@inproceedings{hess2022pmb_nll,
  title={Object Detection as Probabilistic Set Prediction},
  author={Hess, Georg and Petersson, Christoffer and Svensson, Lennart},
  booktitle={European Conference on Computer Vision (ECCV)},
  year={2022}
}

License

This code is released under the Apache 2.0 License.
